Sleeve Foundation Bolt manufactured by LG Industries is a type of mechanical anchor bolt used to fix steel structures, base plates, handrails, and equipment into concrete or masonry. It consists of a threaded bolt combined with an expandable metal sleeve that grips the concrete when tightened.
Design & Working Principle
Made of a threaded bolt, expansion sleeve, nut, and washer.
When the nut is tightened, the bolt pulls up, causing the sleeve to expand outward.
The expanded sleeve creates strong friction against the concrete, providing secure anchorage.
Suitable for post-installation, unlike cast-in foundation bolts.
Material & Finish
Common materials: Carbon Steel, Mild Steel, Stainless Steel (SS 304 / SS 316).
Surface finishes include zinc plated, hot-dip galvanized, or plain.
Corrosion-resistant options available for outdoor and industrial environments.
Sizes & Specifications
Diameter: Typically M8 to M24 (larger sizes on request)
Length: Depends on embedment depth and base plate thickness
Threading: Full thread
Supplied with nut and washer
Sleeve Foundation Bolts Are Specially Designed Anchoring Fasteners Used To Securely Fix Structural Components, Heavy Machinery, Equipment, And Steel Frameworks To Concrete Foundations. Featuring A Protective Sleeve Around The Bolt, These Foundation Bolts Allow For Minor Alignment Adjustments During Installation, Making Them An Ideal Choice For Projects Requiring Precise Positioning And Flexibility. Engineered From High-quality Steel, Sleeve Foundation Bolts Offer Exceptional Strength, Durability Continue
Precision-Engineered Sleeve Foundation Bolts For Adjustable & Secure AnchoringSleeve Foundation Bolts Are Specially Designed Anchoring Fasteners Used To Securely Fix Heavy Machinery, Structural Steel Columns, Base Plates, And Industrial Equipment To Concrete Foundations. Unlike Conventional Foundation Bolts, Sleeve Foundation Bolts Incorporate A Steel Sleeve (pipe) Around The Threaded Rod, Allowing For Positional Adjustment Before Final Grouting Or Tightening. This Unique Design Simplifies Continue
LG Industries Manufacturers Sleeve Foundation Bolt (sometimes Also Called A Sleeve Anchor Or Grouted Foundation Bolt) Is A Type Of Foundation Fastener Used To Anchor Structures, Machinery, Or Equipment To Concrete Foundations. Instead Of Being A Simple Bolt Cast Into Concrete, It Includes A Sleeve That Allows For Positioning And Secure Anchorage — Especially Useful In Heavy-duty And Adjustable Installations. Main Bolt/Rod: A Threaded Rod Or Bolt, Usually Made Of High-strength Steel. Continue
